Two In One Silicone Coated PC Apple IPhone Case Silicone Injection Molding Machine

Two-in-One Silicone-Coated PC Apple iPhone Case Production Liquid Silicone Rubber Injection Molding Machine

Characteristics

1) Compared with the solid rubber molding, the liquid silica gel injection molding does not need the operation procedures such as molding, mixing, pre molding, etc., which saves manpower, material resources and energy, reduces equipment investment and floor space.

2) The injection molding of liquid silica gel can realize the automatic processing under the fully closed condition, eliminate the manual operation deviation, reduce the influence and pollution of various variable factors in the processing, and ensure the dimensional accuracy and internal quality of the product, which is conducive to the application of liquid silica gel in medical treatment.

3) Because the viscosity of liquid silica gel is very low (generally in the range of 10-1000pas), and its fluidity and processability are good, its injection pressure is much lower than that of solid rubber and plastic. Generally, the injection pressure is 20MPa, which can be lower than 1MPa in some cases. Therefore, it can produce products without flash, reduce material waste, and reduce the wear of equipment and mold. In addition, due to the good fluidity of liquid silica gel, it is especially suitable for forming large-scale products, extremely complex shape products or ultra-thin products, such as ultra-thin products with a forming thickness of 0.5mm and a length of 100mm, which is difficult for solid rubber materials to form.

4) The curing rate of liquid silica gel is very fast. During injection molding, the curing reaction can be completed in the range of 160-220 seconds to several minutes, so the molding cycle is short and the production efficiency is high.

5) The back pressure required for liquid silica gel in screw metering is very small, generally less than 1.5MPa. For some liquid silica gel materials with very low viscosity, even no back pressure can be set, which is mainly due to the good fluidity of low viscosity silica gel and the low gas content in liquid silica gel in normal operation. On the contrary, the large back pressure will increase the density of the unvulcanized silica gel and destroy the accurate measurement effect of the metering device.

6) Liquid silica gel does not shrink in the process of injection molding, but due to its high thermal expansion coefficient, it usually shrinks by 2% ~ 3% after demoulding and cooling. The exact shrinkage data depends on the material formula. From the point of view of processing, designers should consider some factors affecting shrinkage in advance.

LSR Dosing unit: More than 20 years experience in LSR area

1.Imported CNC machine to process the components by ourselves in order to decrease the tolerance;

2. Different motor source according to customer's needs:hydraulic ,hydraulic servo,servo;(A and B with synchronous cylinder);

3. Injection precision:≤0.01g;

4. Ratio:1:1 or adjustable(servo motor);

5. Feeding volume :0~4000g/60s(various,basing on its viscosity);

6. Color mix:0.3~4%(stable and even);

7. Pneumatic system:R3/8",6 bar ;

8. Mix mold:static ,dynamic or static +dynamic;

9. Work principle:plunger or gear pump;

Applicable:infants and children;automatic parts;medical;electronics;sports;daily use ;electric power and so on.
